Ultimate UL-DW4.OA
Heavy-duty 4.0-tonne low-profile scissor lift for commercial mechanical bays in Perth, WA, offering surface or flush-mount in-ground installation. The UL-DW4.OA provides a solid 4,000 kg capacity with low drive-on height, ideal for workshops servicing lowered vehicles as well as heavy commercial utes. Features dual hydraulic synchronisation, mechanical safety locking teeth, and emergency manual lowering valves. Keeps workshop bay floors clear of bulky vertical posts, maximising working area for mechanics. Certified to Australian WorkSafe standards with local technical support and parts backup from P&M in Maddington.
Nationwide Freight to Any Commercial Workshop or Transport Depot
Daily dispatch from Maddington. Same-day Perth metro delivery. Regular road freight circuits to Bunbury, Albany, Geraldton, Kalgoorlie, Karratha, and Port Hedland.
Consolidated linehaul freight to major transport depots across Sydney, Melbourne, Brisbane, Adelaide, Darwin, and Hobart with forklift loading support.
Heavy hoists are packaged in heavy-gauge steel frame crates with high-density rust inhibitor wrapping to guarantee pristine arrival at your workshop.
Specifications & Dimensions
| Lifting Capacity | 4,000kg |
| Lifting Height | 1220mm |
| Initial Height | 125mm |
| Total Width | 1920mm |
| Platform Length | 1530-1690mm |
| Locking System | Electric ( No Air Required ) |
| Power | 240V |
| Freight Dimensions | 2080mm x 1780mm x 270mm |
| Freight Weight | 750kg |
| Australian Standard | AS 1418.9 / AS 2550.9 Compliant |
| Warranty Coverage | Commercial Manufacturer Warranty & Local Parts Support |
Workshop Fitment Requirements
To ensure safe operation and compliance with AS 2550.9, confirm that your bay meets the following specifications before hoist delivery:
- Concrete Slab: 125mm - 150mm reinforced concrete (25 - 32 MPa rating).
- Ceiling Clearance: Allow minimum 200mm clearance above total hoist height.
- Power Supply: Dedicated circuit breaker installed by licensed electrician.
Key Inclusions & Features
Speak with a Workshop Technician
Unsure if this unit fits your workshop ceiling height or vehicle wheelbase? Call our Maddington technical team for bay layout advice.
