Ultimate Z-9000LS 4T

Name: Ultimate Z-9000LS 4T
Brand: Ultimate
Price: 4400 AUD
Availability: InStock
Rating: 4.9 (48 reviews)

Commercial Trade Price

$4,400.00 AUD + GST

Ready to ShipDirect Warehouse Stock

Interstate Delivery: Daily dispatch to all AU states & regional hubs

Hubs

Dependable 4.0-tonne 2-post vehicle hoist for commercial bays in WA, WorkSafe compliant with symmetric arm geometry for general vehicle maintenance. The Z-9000LS is built for busy workshops needing a reliable everyday lifter for passenger sedans, wagons, and light commercial utes. Features dual hydraulic cylinders, synchronised steel cables, and a rigid overhead beam with an automatic padded shut-off switch to protect tall vehicle roofs. Supplied with standard drop-in lift pads and height adaptors. Available directly from our Perth warehouse with full workshop installation or delivery across regional Western Australia.

Lifting Capacity4,000kg

Lifting Height1920mm

Overall Height3650mm / 3900mm

Power SupplySingle or 3-Phase Available

Call (08) 9209 1044

Existing P&M Service Client? You qualify for an exclusive 5% loyalty discount on equipment purchases. Mention your workshop account when inquiring.

Australia-Wide Logistics

Nationwide Freight to Any Commercial Workshop or Transport Depot

Perth & WA Regional

Daily dispatch from Maddington. Same-day Perth metro delivery. Regular road freight circuits to Bunbury, Albany, Geraldton, Kalgoorlie, Karratha, and Port Hedland.

Interstate Capital Depots

Consolidated linehaul freight to major transport depots across Sydney, Melbourne, Brisbane, Adelaide, Darwin, and Hobart with forklift loading support.

Secure Timber Packaging

Heavy hoists are packaged in heavy-gauge steel frame crates with high-density rust inhibitor wrapping to guarantee pristine arrival at your workshop.

Direct Freight Depots & Delivery Corridors:View All 14 Australian Freight Hubs

Sydney (NSW)Melbourne (VIC)Brisbane (QLD)Perth (WA)Adelaide (SA)Gold Coast (QLD)Newcastle (NSW)Canberra (ACT)Sunshine Coast (QLD)Geelong (VIC)Wollongong (NSW)Townsville & Cairns (QLD)Darwin (NT)Hobart (TAS)

Technical Engineering Data

Specifications & Dimensions

Lifting Capacity	4,000kg
Max Lifting Height	1920mm
Total Height	3650mm / 3900mm
Total Width	3550mm
Inner Width	3000mm
Power	240V or 415V
Freight Dimensions	2860mm x 950mm x 450mm
Freight Weight	675kg
Minimum Concrete Requirement	125mm - 150mm Reinforced (25+ MPa)
Australian Standard	AS 1418.9 / AS 2550.9 Compliant
Warranty Coverage	Commercial Manufacturer Warranty & Local Parts Support

Workshop Fitment Requirements

To ensure safe operation and compliance with AS 2550.9, confirm that your bay meets the following specifications before hoist delivery:

Concrete Slab: 125mm - 150mm Reinforced (25+ MPa).
Ceiling Clearance: Allow minimum 200mm clearance above total hoist height.
Power Supply: Dedicated circuit breaker installed by licensed electrician.

Design Highlights

Key Inclusions & Features

Clear Floor Design

WorkSafe Design Registered

Asymmetric & Symmetric Configuration

Included Add On's - 4WD & Light Commercial Lift Pad Extensions

Need Sizing Guidance?

Speak with a Workshop Technician

Unsure if this unit fits your workshop ceiling height or vehicle wheelbase? Call our Maddington technical team for bay layout advice.

(08) 9209 1044

Buyer Guidance

Frequently Asked Questions

For Perth metropolitan workshops, we offer same-day collection or priority 24-hour delivery from our Maddington warehouse. For regional WA (Bunbury, Kalgoorlie, Pilbara) and interstate destinations (Sydney, Melbourne, Brisbane, Adelaide), freight transit typically takes 2 to 6 business days.
