ULTIMATE UL-6500E 6.5T
The UL-6500E is a heavy duty four post vehicle hoist with a 6,500kg lifting capacity. Designed for busy workshops that need dependable, high-capacity lifting, ideal for everyday servicing, repairs and inspections. Built to handle cars, utes and light commercial vehicles, the UL-6500E is a tough, practical and reliable choice for demanding daily workshop use.
Nationwide Freight to Any Commercial Workshop or Transport Depot
Daily dispatch from Maddington. Same-day Perth metro delivery. Regular road freight circuits to Bunbury, Albany, Geraldton, Kalgoorlie, Karratha, and Port Hedland.
Consolidated linehaul freight to major transport depots across Sydney, Melbourne, Brisbane, Adelaide, Darwin, and Hobart with forklift loading support.
Heavy hoists are packaged in heavy-gauge steel frame crates with high-density rust inhibitor wrapping to guarantee pristine arrival at your workshop.
Specifications & Dimensions
| Lifting Capacity | 6,500kg |
| Lifting Height | 1700mm |
| Column Height | 2164mm |
| Total Width | 3303mm |
| Drive Through Clearance | 2993mm |
| Platform Length | 5696mm |
| Total Length | 6746mm |
| Power | 240V or 415V |
| Freight Dimensions | 5780mm x 740mm x 780mm |
| Freight Weight | 1,800kg |
| Minimum Concrete Requirements | 110mm / Be Reinforced |
| Australian Standard | AS 1418.9 / AS 2550.9 Compliant |
| Warranty Coverage | Commercial Manufacturer Warranty & Local Parts Support |
Workshop Fitment Requirements
To ensure safe operation and compliance with AS 2550.9, confirm that your bay meets the following specifications before hoist delivery:
- Concrete Slab: Minimum 150mm reinforced concrete (25 - 32 MPa rating).
- Ceiling Clearance: Allow minimum 200mm clearance above total hoist height.
- Power Supply: Dedicated circuit breaker installed by licensed electrician.
Key Inclusions & Features
Speak with a Workshop Technician
Unsure if this unit fits your workshop ceiling height or vehicle wheelbase? Call our Maddington technical team for bay layout advice.
